Unlock seamless 360° creativity with HEIPI’s Panoramic Panning Base PAN01 – the ultimate tool for precision stitching, astrophotography, and cinematic motion. Designed for photographers and videographers who demand versatility, this guide breaks down its six core applications with step-by-step instructions.

1. Quick-Release Plate Installation & Adjustment

The Foundation of Stability
Compatible with Arca-Swiss standard systems, the PAN01 ensures secure camera mounting:
  1. Unlock: Turn the gear-shaped knob counterclockwise.
  2. Align & Insert: Slide the quick-release plate into the clamp, using 360 Degree Scale for millimeter-precise positioning.
  3. Lock: Tighten the knob clockwise until fully secured.
  4. Anti-Drop Safety:
    1. Long plates: Bottom limit screws prevent slippage.
    2. Square plates: Retractable Anti-loosen Screw engages when unlocked.

2. Using the Panoramic Base & Bubble Level

Perfect Horizons, Every Time
Achieve buttery-smooth rotations with the panoramic base:
  • Unlock Rotation: Turn the spindle-shaped knob counterclockwise for seamless 360° panning.
  • Level Precisely: Use the built-in Bubble Level to eliminate tilted horizons.
  • Lock Instantly: Secure your angle by tightening the knob clockwise.
Pro Tip: For multi-row panoramas, rotate in 15°–30° increments using the 360 Degree Scale.

3. Arca-Swiss Ball Head Integration

Expand Your Shooting Angles
Transform standard ball heads into panoramic powerhouses:
  1. Attach the PAN01 base to any Arca-Swiss compatible head (e.g., HEIPI KF50 Series).
  2. Unlock the panoramic base to add a second axis of rotation.
  3. Recompose shots without moving the tripod – ideal for architectural or landscape stitching.

4. Magic Arm Rigging for Creative Angles

Unleash creativity with Modular Mounting
Leverage the PAN01’s 1/4“ Treaded Hole + 4x ARRI Positioning Pin Holes for unconventional setups:
  • Step 1: Attach the HEIPI MA175 Magic Arm (or third-party arm) via the 1/4“ Treaded Hole and the ARRI positioning pin hole.
  • Step 2: Extend/rotate the arm to position your camera over edges.
  • Step 3: Lock all knobs firmly – never forget this!

5. Fluid Video Pan/Tilt Head Pairing

Cinematic Motion Made Simple
Upgrade video heads for buttery pans:
  1. Fix the PAN01 to your pan/tilt head’s quick-release plate.
  2. Mount the plate back at the pan/tilt head and mount your camera at the PAN01.
  3. Unlock the knob for drag-free horizontal movement during panning or tracking shots.
Ideal for: Real estate tours, hyper-lapse or aerial photography.

6. Astrophotography & Equatorial Mounts

Capture the Stars with Precision
Create flawless star trails and Milky Way panoramas:
  1. Mount Setup:
    1. Attach an equatorial mount to your HEIPI W28S tripod via 3/8" screw.
    2. Fix the ball head on the equatorial mount and adjust its direction properly.
    3. Secure the PAN01 to the Arca-Swiss standard ball head.
  2. Camera Calibration:
    1. Use PAN01’s 360 Degree Scale to align shots for multi-position stitching.
    2. Rotate in exact increments (e.g., 60° for 6-image astro pans).
  3. Lock & Shoot: Tighten all knobs to prevent drift during long exposures.

Why do you need the HEIPI Panoramic Panning Base PAN01?

  • Universal Compatibility: Works with Arca-Swiss standard mount, 1/4“ Treaded Hole with ARRI Positioning Pin Holes.
  • Zero-Drop Security: Spring-loaded failsafes protect heavy gear.
  • All-in-One Workflow: Replace multiple clamps/adapters with one tool, set up a variety of DIY combinations, and keep compact and light
